Angle of view are the specific area of teh scene that is captured by a lens in the cameras frame. The angle of view of the lens will determine the amount of the scene that the camera can capture. Angles of view can be either wide or narrow.
The focal length of the lens and the size of the sensor that is located inside the camera determine the angle of view of an lens. Lenses with a wide angle of view will capture a large portion of the scene. However, lenses with a wide angle of view can create distortions in the perspective of the scene.
Angle of View in Cameras: Lenses, Sensors and Distance
Lenses with a narrow angle of view will only capture a small portion of the scene. Narrow angles of view is often used in photography to allow the subject of interest to be isolated from the background of the scene. Based off the angle of view that they emit, lenses can be categorized into several different types.
Fisheye and ultra wide lenses emit a very wide angle of view and capture a massive portion of the scene. Normal focal length lenses creates an angle of view that is similar to how the human eye sees the world around them. These lenses is often used in photography to allow the subject of interest to be viewed in a similar fashion to the human eye.
Telephoto and super-telephoto lenses emit narrow angle of view. These lenses focus on a small portion of the scene and compress the distance between objects of interest in the scene. The size of the sensor of the camera changes how a specific focal length lens functions within the camera.
A 50mm lens will emit a specific angle of view when used on a camera with a full-frame sensor. However, if the photographer use the same 50mm lens on a camera with a smaller sensor, the angle of view of that lens will be narrower. The smaller sensor will crop the scene that is recorded by the camera.
Therefore, the 50mm lens will create a smaller angle of view when that lens is used on a camera with a smaller sensor. Thus, you should of considered the size of the sensor that is used with a lens when selecting that lens for use in a camera. The distance between the person taking the photograph and the subject of the photograph can also impact the angle of view.
If a person stands too close to the subject in a photograph, the feature of that subject will be exaggerated in the photograph. For these reasons, many photographers use telephoto lenses when taking portraits of individuals. Instead of standing too close to the individual that is to be featured in the photograph, the photographer can use a telephoto lens to achieve the same framing for the photograph.
Thus, the photographer should consider the distance between the camera and the subject of the photograph as another factor when taking the photograph. Due to the need for changes in aspect ratio in video production, the angle of view of the video cameras must also be considered. When the aspect ratio of the video cameras is changed, the sensor that take the videos are cropped.
This cropping of the sensor changes the angle of view of the video cameras, even though the lenses that are used in those cameras do not change. For example, if the video cameras are to be used to film vertical videos, the horizontal angle of view will be significantly narrowed. For this reason, video cameras that film vertical videos will require wider lenses than those that film horizontal videos.
Security cameras and drones utilize the angle of view of the cameras to determine the coverage of those cameras. Security cameras with a wider angle of view will cover a larger area of interest than security cameras with a narrow angle of view. However, security cameras with a very wide angle of view will make it more difficultly identify the features and faces of individuals who are located further from the security camera.
Additionally, drones use the fixed lenses to determine the angle of view of the lenses and, thus, the amount of the landscape that the drone is able to capture in a single frame. The angle of view of the drone cameras is used to determine the total area of coverage that the drone will have during its flights. Thus, the angle of view of security cameras and drones is a measurement of the coverage that these devices will have.
